Description
2023 MT-09 IN
ACTION
Unleash Your Ultimate Ride: Embark on the MT-09 Adventure
SPECIFICATIONS
ENGINE
Engine Type
890cc liquid-cooled, DOHC, inline 3-cylinder; 4 valves per cylinder
Bore x Stroke
78.0mm x 62.1mm
Compression Ratio
11.5:1
Fuel Delivery
Fuel injection with YCC-TTransmission
6-speed; multiplate assist and slipper clutch
Final Drive
Chain
CHASSIS
Suspension / Front
41mm inverted fork, adjustable preload, compression and rebound; 5.1-in travel
Suspension / Rear
Single shock, adjustable preload and rebound damping; 4.8-in travel
Brakes / Front
Dual 298mm hydraulic disc; ABS
Brakes / Rear
245mm hydraulic disc; ABSTires / Front
120/70ZR17M/C
Tires / Rear
180/55ZR17M/C
DIMENSIONS
L x W x H
82.3 in x 31.3 in x 46.9 in
Seat Height
32.5 in
Wheelbase
56.3 in
Rake (Caster Angle)
25.0°
Trail
4.3 in
Maximum Ground Clearance
5.5 in
Fuel Capacity
3.7 gal
Fuel Economy
49 MPG
Wet Weight
417 lb
