YAMAHA T-MAX 2024

You work hard. You play hard. Time is your most valuable commodity. And you appreciate authentic style and proven quality. So when you see what the TMAX Tech MAX has to offer, it’s probably going to be one of the easiest and smartest decisions you’ve made for a long time.

ENQUIRE NOW
Category:

Description

2024 T-MAX IN

ACTION

STRAIGHT TO THE MAX

SPECIFICATIONS

  • ENGINE

    Engine Type

    4-stroke, Liquid-cooled, DOHC, 4-valves, Parallel twin-cylinder

    Displacement

    562 cc

    Bore x Stroke

    70.0×73.0 mm

    Compression Ratio

    10.9:1

    Maximum power

    35.0 kW @ 7,500 rpm

    Maximum torque

    55.7 Nm @ 5250 rpm

    Lubrication system

    Dry sump

    Fuel system

    Fuel Injection

    Ignition system

    TCI

    Starter system

    Electric

    Transmission system

    V-Belt Automatic

    Fuel consumption

    4.8 L/100 km

    CO2 emission

    112 g / km

  • CHASSIS

    Suspension / Front

    Telescopic forks

    Front Travel

    120 mm

    Suspension / Rear

    Swingarm

    Brakes / Front

    Hydraulic dual disc brake, Ø267 mm

    Brakes / Rear

    Hydraulic single disc brake, Ø282 mm

    Tires / Front

    120/70R15M/C 56H Tubeless

    Tires / Rear

    160/60R15M/C 67H Tubeless

  • DIMENSIONS

    Overall length

    2.195 mm

    Overall width

    780 mm

    Overall height

    1.415 mm – 1.525 mm(electric windscreen)

    Seat height

    800 mm

    Wheelbase

    1.575 mm

    Minimum ground clearance

    135 mm

    Fuel Capacity

    15 L

    Wet Weight

    220 kg
