Description
2024 VIKING VI EPS IN
ACTION
SPECIFICATIONS
ENGINE
Engine Type
686cc liquid-cooled SOHC 4-stroke; 4 valves
Bore x Stroke
102.0mm x 84.0mm
Compression Ratio
10.0:1
Fuel Delivery
Yamaha Fuel Injection (YFI)
Transmission
Ultramatic V-belt with all-wheel engine braking; L, H, N, R
Final Drive
On-Command; 3-way locking differential; 2WD, 4WD, locked 4WD; shaft drive
Fuel Capacity
9.7 gal
CHASSIS
Suspension / Front
Independent double wishbone; 8.1-in travel
Suspension / Rear
Independent double wishbone with anti-sway bar; 8.1-in travel
Brakes / Front
Dual hydraulic disc
Brakes / Rear
Dual hydraulic disc
Tires / Front
AT25 x 8-12
Tires / Rear
AT25 x 10-12
DIMENSIONS
L x W x H
159.5 in x 64.0 in x 76.6 in
Wheelbase
115.6 in
Fuel Capacity
9.7 gal
Wet Weight
1,761
