Description
2024 YZ125 IN
ACTION
TWO‑STROKE EVOLUTION
SPECIFICATIONS
ENGINE
Engine Type
125cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke
54.0mm x 54.5mm
Compression Ratio
8.2~10.1:1
Fuel Delivery
Hitachi Astemo® Keihin PWK38S carburetor
Transmission
Constant-mesh 6-speed; multiplate wet clutch
Final Drive
Chain
CHASSIS
Suspension / Front
KYB® Speed-Sensitive System inverted fork; fully adjustable, 11.8-in travel
Suspension / Rear
KYB® single shock; fully adjustable, 12.4-in travel
Brakes / Front
Hydraulic disc, 270mm
Brakes / Rear
Hydraulic disc, 240mm
Tires / Front
80/100-21 Bridgestone® Battlecross X20F
Tires / Rear
100/90-19 Bridgestone® Battlecross X20
DIMENSIONS
L x W x H
84.1 in x 32.5 in x 51.0 in
Seat Height
38.6 in
Wheelbase
56.9 in
Rake (Caster Angle)
26°
Trail
4.3 in
Maximum Ground Clearance
14.4 in
Fuel Capacity
1.8 gal
Wet Weight
209 lb
